DC 6V 12V 24V PWM DC Motor Speed Controller Forward and Reverse Switch Linear Actuator Motor Controller Adjustable Speed Control

Description: 1. DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM) 2. Control the forward or reverse direction and the stop of DC motor by button switch. 3. Press the green button, the motor reverses rotates; and release the button, the motor stops 4. Press the red button, the motor clockwise rotates; and release the button, the motor stops

Feature: 1. Input supply voltage: 6V - 24V DC 2. PWM frequency: 21kHz; 3. Duty Cycle adjustable: 0%-100% 4. Current rating: 30A 5. Potentiometer with switch function 6. The display range of 3-digit LED display is "000"-"100". (For example, displayed "055", it means that the PWM output duty cycle is 55%.) 7. Product Dimensions: 57 * 37 *21mm

Package Included: 1 x PWM Motor Speed Controller
