Car HH OBD Bluetooth Scanner Read and Erase Car Fault Code Engine Light Scanner Code Reader for Andriod Pc iOS

Origin : Mainland China Material : ABS Size : about 6.5*4.5cm

Specification  Category:V1.5 Auto fault detector  Material: ABS  Size: about 6.5*4.5cm  Communication: for Bluetooth 5.1  Support system: IOS, Android, Symbian, Windows  Working voltage: 9v~16v  Working temperature: -40℃~65℃  Package includes: 1*OBD2 Bluetooth V1.5 car scanner (with teaching QR code on the back of the box)

Compatible systems:  Software support platform: Windows XP, Windows 7/8, Android, Symbian, Windows PC  Compatible software:  Window: ScanMaster-ELM, ScanTool.net, PCMSCAN ELM, etc.  Android: Torque, DashCommand, OBD Auto Doctor, Auto Doctor, Mini OBD, EOBD, etc.  Symbian: OBDScope

Supported protocols:  1.SAE J1850 PWM (41.6Kbaud)  2.SAE J1850 VPW (10.4Kbaud)  3.ISO9141-2 (5 baud init, 10.4 Kbaud)  4.ISO14230-4 KWP (5 baud init, 10.4 Kbaud)  5.ISO14230-4 KWP (fast init, 10.4 Kbaud)  6.ISO15765-4 CAN (11bit ID, 500 Kbaud)  7.ISO15765-4 CAN (29bit ID, 500 Kbaud)  8.ISO15765-4 CAN (11bit ID, 250 Kbaud)  9.ISO15765-4 CAN (29bit ID, 250 Kbaud)

Basic functions  1: Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).  2: Clear trouble codes and turn off the MIL ('Check Engine' light)  3: Display current sensor data, including:  4: Engine RPM  5: Calculated Load Value  6: Coolant Temperature  7: Fuels System Status  8: Vehicle Speed  9: Short Term Fuels Trim  10: Long Term Fuels Trim  11: Intake Manifold Pressure  12: Timing Advance  13: Intake Air Temperature  14: Air Flow Rate  15: Absolute Throttle Position  16: Oxygen sensor voltages / associated short term fuels trims  17: Fuels System status  18: Fuels Pressure  19: Many others
