Multi Function Automotive Circuit Test S Diagnose Cables Wiring Accessories Kit

Features: Wiring Assistance Kit: A perfect wiring circuit checking tool. Can be used quickly for adjustment and assists technician in checking the car problems accurately. Its variable Resistors can be used to simulate coolant temperature sensor signals, throttle valve sensor signals to vehicle ECU to avoid unnecessary new parts replacement. Complete set of various wires in the case that are suitable for most European, American and Japanese made terminals. Equipped with 2 sets of LED lights; it can be used to monitor Hall Effect, photoelectric signals, nozzles, electromagnetic valve of transmission shift gears and control signals. SRS connector provided can simulate airbag and routed contracting device of safety belt to avoid accident or miss judgment. Functions: 1.When checking the parts, it could connect the back of terminal directly, would not to damage the circuit, reduce thecircuit rust and avoid to adding impedance. 2.Apply to any Automotive Multimeter, the extended line of probe for oscilloscope. More convenient connection and checking rapidly. 3.When checking the electric current, only use the lines to connect the circuit, do not need to cut the electric wires. 4.Variable Resister can simulate the pretend signal of coolant temperature sensor, throttle valve sensor and send thepretend signal to computer. It would avoid risk to change the new parts again. 5.Equip 2 sets LED light. It can supervise hall effect, photoelectric signal, nozzle, electromagnetic valve, electromagneticvalve of transmission shift gear....and control signals. 6.SRS Connector can simulate airbag and routed contracting device of safety belt to avoid accident or miss judgment. 7.Various wires in this box, it is suitable for the Europe, America and Japan terminal. High common use and convenience. Specification: Condition: 100percent Brand New Material: ABS+PVC Color: As picture shown How to use this circuit to test the cable: 1.Disconnect the electronic connector 2.Choose the matching connector adapter to connect the signal cable 3.Series connect the connected signal cable between electronic connectors 4.Connect the instrument test table pen and transfer switch wiring connection hole Package List: 2 * 5k Ohm Potentiometer (Variable Resister) 2 * LED Stroboscope 2 * SRS Connector 2 * Alligator Clip 2 * Prober 2 * Red Wire Harness Prober 2 * Black Wire Harness Prober 2 * 1 to 2 Connector 2 * Thorn Clip 2 * Connecting Line 72 * Red Strip Connecting Line 72pcs Red Strip Connecting Line: 1.5mm (Male Female)+Connector of Banana Sockets (3pcs each) 2.0mm (Male Female)+Connector of Banana Sockets (3pcs each) 3.5mm (Male Female)+Connector of Banana Sockets (3pcs each) 4.0mm (Male Female)+Connector of Banana Sockets (3pcs each) 0.7mm (Male Female)+Connector of Banana Sockets (3pcs each) 0.8mm (Male Female)+Connector of Banana Sockets (3pcs each) 1.2mm (Male Female)+Connector of Banana Sockets (3pcs each) 2.0mm (Male Female)+Connector of Banana Sockets (3pcs each) 2.5mm (Male Female)+Connector of Banana Sockets (3pcs each) 3.0mm (Male Female)+Connector of Banana Sockets (3pcs each) 5.0mm (Male Female)+Connector of Banana Sockets (3pcs each) 6.0mm (Male Female)+Connector of Banana Sockets (3pcs each)
