Mini Wireless Receiver Specification Data
Encoding Type: Intelligent Learning Code 1527
Modulation Mode:ASK
RF Frequency: 433MHz
Input Voltage: AC 85V 240V
Max current: 10 Amp
Remote distance : up to 50m (theoretical distance)
Wired Connection Way: Fixed Wiring Pillar
Output Terminal: L /N
L : Living line
N : Neutral line
Size:42*48*23mm
Color: White (Outside Shell)
Remote control Specification Data
Control Distance : 100 meters in open sapce
RF frequency : 433MHz
Support encoding : 1527 Leaning code
Size:60*30MM
Battery : CR2016 2pcs * ( include )
Working mode:
1. Inching mode: press the remote controltherelaywill connect, and thenrelease the remote controlto disconnect the relay;
2. Self-locking mode: press the remote controltherelaywill connect, and then press the remote controlagainto disconnect the relay;
3. Interlock mode: press the remote control key A toconnect the relay, and press the remote control key B to disconnect relay.
4. Delay mode: press the remote controltherelaywill connect, release the remote control and start timing. After 5S, 10S and 15S (3 gears), the relay will be automatically closed.
About Learning and clearing Method:
Momentary: press the Learning Button 1 time. the Led indicator flash 1 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Toggle: press the Learning Button 2 time. the Led indicator flash 2 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Latched: press the Learning Button 3 time. the Led indicator flash 3 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Delay time (5S): press the Learning Button 4 time. the Led indicator flash 4 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Delay time (10S): press the Learning Button 5 time. the Led indicator flash 5 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Delay time (15S): press the Learning Button 6 time. the Led indicator flash 6 time, Then press transmitter, the Led indicator flash for 3 times, learning successfully.
Clearning: Press the Learning button 8S . Until the receiver Led indicator flash for 3 times and OFF, it mean Clearing Code
