LED Display Digital Temperature Controller DC 12V/24V/AC110-220V Mini Thermostat Controller with Heat/Cooling Control Instrument

Function description: P0: Cooling or heating mode P1: Return differential setting P2: Upper limit of maximum temperature setting P3: Minimum temperature setting a lower limit P4: Temperature correction P5: Delay start time (unit: minute) Specifications: Product name: Digital temperature controller Power supply: DC 12V/ DC 24V/AC 110V-220V Temperature monitoring range:-55 ℃-120 ℃ Resolution ratio: 0.1 °c (-9.9-99.9); 1 °c (other range) Display color: Red/Blue Measuring accuracy: ± 0.1 °c Control accuracy: 0.1 °c Sensor: ntc10k waterproof sensor Output: relay contact capacity 20a 12V/10a 220V Environmental requirements: -10-60 °c, air humidity 20%-85% rh Dimension: 79mm * 43mm * 26mm Cut size: 73mm * 39mm Sensor wire: 1 meter

Package Includes: 1*Digital temperature controller

Notes: 1. Due to the difference between different monitors, the picture may not reflect the actual color of the item. 2. Please allow slight dimension differences due to different manual measurements. Thank you for your understanding.
