Channel 48 CH + 24 CH;
Control protocol IRC Tramp, support OSD adjustment;
Power: PIT 25mW, 400 mW, 800 mW, 2500 mW;
Efficient DC / DC power supply support 7-36V;
Select high strength aluminum alloy CNC shell and built-in micro turbine fan active heat dissipation enhancement power stable transmission;
The transmitter has a temperature control protection function to prevent the long time ground control transmitter temperature is too high;
Support for external audio input;
Support for 5V voltage output;
Product Parameter
Transmitter (sky end):
Input voltage: 7-36V DC (2-6S)
Output voltage: 5V/0.5A
Weight: 15.6g (with enclosure, without antenna)
Dimensions (length, width and height): 38.7 * 26 * 11MM
Video system: PAL / NTSC
Emission frequency: 48 CH + 24 CH, see the frequency point table for details
Between the conventional frequency group (48 CH) and the extended frequency group (24 CH), press the power button (Power) and the FM key (Band / CH) for more than 5 seconds
Channel selection: frequency band / frequency point adjustment button: press 3 seconds to switch frequency band, press switch frequency point
Emission power: 34 dBm ± 1 dBm (MAX)
Power adjustment: power adjustment button, short press to switch
Number of power: fourth gear, 25 mW, 400 mW, 800 mW, 2500 mW;
Antenna interface: MMCX
Modulation type: FM
