Feature:
1. EXCITATION PMG: The generator voltage regulator uses the exciter self PMG as the excitation power supply, 5060Hz excitation field output, stable and reliable.
2. WORKING VOLTAGE: The voltage regulation rate of the voltage control board is +1.0percent , 82VAC at 200V input, 45VAC at 110V input, has a wide range of application.
3. PARALLEL USE: The regulator can be used in parallel, and the cross copper plate can be set to match different generator, suitable for self excited brushless generator.
4. FUNCTIONS: Support low frequency protection inflection adjustment, voltage frequency slope adjustment, DROOP parallel connection, single phase voltage detection.
5. PLASTIC SHELL: The generator voltage regulator shell is made of ABS material, light in weight, wear resistant and aging resistant, safe and reliable, has a long service life.
Specification:
Item Type: Automatic Voltage Regulator
Model: AS480
Material: ABS
Voltage: 100264V AC
Single Phase Frequency: 5060Hz excitation field output
Voltage: 82VAC at 200V input, 45VAC at 110V input
Current: 5A continuously, 7.5A in non continuous 10 seconds
Resistance: 15 Ohm minimum
Voltage Regulation Rate: +1percent
External Voltage Adjustment: +10percent when external voltage finetuning 1K1W potentiometer
Working Temperature: 4070 celsius
.
Package List:
1 x Voltage Regulator1 x User Manual
EXCITATION PMG: The generator voltage regulator uses the exciter self PMG as the excitation power supply, 5060Hz excitation field output, stable and reliable.
WORKING VOLTAGE: The voltage regulation rate of the voltage control board is +1.0percent , 82VAC at 200V input, 45VAC at 110V input, has a wide range of application.
PARALLEL USE: The regulator can be used in parallel, and the cross copper plate can be set to match different generator, suitable for self excited brushless generator.
FUNCTIONS: Support low frequency protection inflection adjustment, voltage frequency slope adjustment, DROOP parallel connection, single phase voltage detection.
PLASTIC SHELL: The generator voltage regulator shell is made of ABS material, light in weight, wear resistant and aging resistant, safe and reliable, has a long service life.
