Feature:
1. Self?identified voltage. Smooth start without for Hall.
2. With or without for Hall automatic identification.
3. Motor short circuit, open circuit, for Hall, power protection.
4. 32?bit single?chip microcomputer, learning faster and more efficient.
5. The drive motor starts more smoothly and travels more comfortably.
6. The climbing ability is strong, the motor running noise is low, and the tire noise is eliminated.
7. The aluminum shell is thicker and heat dissipation is better. The motherboard solution is better. Power tubes, capacitors, copper bars, etc. are better.
Specification:
Condition: 100percent brand newItem type: Electric Scooter Controller Material: aluminiumColor: As picture shownSize: Approx. 16x8.8x4.8cm6.3x3.5x1.9inWeight: Approx. 460g Voltage: 48V64V
Power: 450WConnector function:
1. Red, black and orange (power cord + electric door lock cord)
2. High battery brake cable
3. Low battery brake cable
4. Antitheft power cord
5. Turn handle line
6. Motor for Hall
7. Third gear overspeed
8. Antitheft alarm
9. Yellow, green and blue 3 round headmotor wire (3 pcs)
10. White line black headlearning line (2pcs)
11. Green line green headinstrument line
12. Orange Black headCruising Line
13. Black line black headcruising line.
Package List:
1 x Controller
Note:
Learning line learning: Overhead motor, connect the power supply, motor, for hall, handle, and plug learning line (two white wires), the motor will automatically rotate slowly after opening the key, if the motor reverses, please learn the line After disconnecting, plug in again (or turn the handle), the motor will rotate forward at this time, and the learning line must be disconnected after learning. This product is a general type for Hall and no for Hall.Self?identified voltage. Smooth start without for Hall.
With or without for Hall automatic identification.
Motor short circuit, open circuit, for Hall, power protection.
32?bit single?chip microcomputer, learning faster and more efficient.
The drive motor starts more smoothly and travels more comfortably.
