iCubeSmart 3D8MINI Led DIY Electronic Led Cube Soldering Practice Led Kit Practice Electric Kit Craft Electronic Work Kit Cube, Kit, Kit, Kit,

Welcome to MJ Select. We are Japanese seller. We ship authentic items from Japan. Please enjoy shopping with peace of mind! -------------------------------------------- 【About Included Manuals】 If a manual is included, it will primarily be in Japanese. We recommend using image translation apps if needed. 【Voltage Compatibility】 When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction. 【Plug Type】 Our products use Japanese plug types (A or B type). Please use a conversion adapter if necessary. 【Important Note on Transformers and Adapters】 A transformer adjusts voltage to match your device’s requirements. A conversion adapter only changes the plug shape and does not adjust voltage. Using only a conversion adapter without a transformer may result in damage to the product. 【Liability】 We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer. -------------------------------------------- [Product use] This is a DIY 3D LED cube light kit. Consisting of 128 red LEDs, 128 green LEDs, 128 blue LEDs, and 128 white LEDs, various spectacular light videos will appear. Students can now apply welding practice during electronic classes. You can also send it as a special present. The gap between each light will be 1.3cm, and the finished size will be 11x11x12cm. [Easy to make] The PCB motherboard parts included in the package have already been welded and tested, and you can weld the LED lights yourself. Buyers need to have basic electronic knowledge and simple welding skills. There are 64 round holes on the motherboard to fix the LED lights, making welding easy. [Modifiable] The main board of this cube is built-in with more than 20 amazing animation effects. Users can view the animation after welding and plugging the USB power supply. Users can also change the animation displayed through the 3D software we provide. Our 3D software can directly generate a HEX write file and download that HEX file to the LightCube for execution. [Motherboard function] The size of the PCB motherboard function is 11*11cm, uses a 5V USB cable, there is a button on the bottom of the motherboard to change the image (reset, start/stop, next, simply cycle/all cycle). [Professional Service] iCubeSmart has been designing LED cubes for 9 years now. Our company has designed various LED cubes and other DIY products. If you have any questions about purchasing our products, if any parts are missing, and if you wish to change the image, please contact our professional service team. We provide lifelong technical service. When you receive the goods, just weld the LED lamp according to the paper welding instructions and plug in the 5V USB power supply to display a wonderful lighting effect. The main board already has over 20 gorgeous animation effects built-in. If you need to modify the pattern you are seeing, you can download the information in an electronic file from the following link: This includes clearer pictures of the manufacturing process, 3D animation software and how to use it, and how to download the program. Package contents: 1. Welded electronic board (11*11cm) 2. USB program downloader 3. USB-DC charging cable 4. 0.8mm tinned iron wire 80cm 5. White electric wire 100cm 6. 1 piece 2mm acrylic strip (used to bend the LED light) 7. Atomized high brightness light 3mm LED light, 150 pieces red LED, 150 pieces green LED, 150 blue LEDs, and 150 white LEDs (please read the instruction manual for how to line them up, in fact only 512 lights need to be used, to prevent damage, replace them) (includes a light). 8. Red and black wires to test the LED. 9. Instruction manual Product specifications: LED metal foot length: 17 mm Microcontroller: STC12C5A60S2 Driver chip: 74HC573 + APM4953 (8 horizontal rows are positive poles, 64 vertical rows are negative poles)
