Operating Temperature : standard
High Power Class D Digital Power Amplifier Power amplifier chip: original TDA7498E (TDA7498L is 2X80W chip, TDA7498 is 2X100W chip, TDA7498E is 2X160W chip) Output power: 2X160W (using 4 ohm impedance speaker unit, input voltage 36V DC, output power 160W + 160W)
Working voltage: 15~ 24VDCdirect currentWith input polarity to reverse protection (the real power of the speaker is large enough, the recommended voltage is 24V, DC power above 8A, and the power supply power is too small, which will distort and break the sound, etc.)
Speaker impedance: 4 ohms 6 ohms 8 ohms
Heat dissipation method: temperature control forced air cooling (the temperature of the heat sink is high to a certain extent, and the fan operation forces heat dissipation)
Work efficiency: 85% (official data)
Support BTL mode (J1, J2, J3, J4 short connection on the back of the power amplifier board) 36V power supply 3 ohm mono 220W output (TDA7498, TDA7498L chip does not support this function)
