HRM10 Internal Resistance Tester High Precision Voltage Measurement Device

Feature: High-definition color screen display: TFT high-definition color screen is used, the screen layout is ingenious, the function data is clear at a glance, and the visual recognition efficiency is faster and smoother Sorting and comparison function: Eight groups of voltage and resistance values are pre-set. Whether it is batch screening of high-quality batteries or precise positioning of problem batteries, it can be completed in an for instant, greatly improving work efficiency Full-process recording: Equipped with automatic retention of test records, so that the test results are clear at a glance, and say goodbye to vague memories. It can also be connected to a computer to export and analyze test data Touch and know: The test uses a Kelvin 4-wire connection to connect and measure, avoiding the influence of wire resistance and contact resistance, and improving test accuracy Data retention: 1-click pause, the measured data is permanently displayed Automatic shutdown mode: you can freely choose the automatic shutdown mode or set a specific shutdown time

Specifications: Part Name: Internal resistance tester Color: As show Material: Plastic Model: HRM-10 Range: Voltage 0~±100V (DC); Resistance 0~200Ω Accuracy: Voltage ±0.5%; Resistance ±0.5% Gear: Voltage: Automatic, 1V, 10V, 100V; Resistance: Automatic, 20mΩ, 200mΩ, 2Ω, 20Ω, 200Ω Instrument test signal frequency: AC 1Khz Charging: TYPE-C interface (5V/1A) Built-in battery: 1000mAh lithium battery User calibration: Support Sorting mode: Support Historical record: Support Record data export: Support Working environment: -10℃—+45℃, relative humidity
