Genb Hiace TRH/KDH200 Series (4WD) Stroke Stopper SSB02H

• ■Compatible model: Hiace ■Compatible model: TRH/KDH200 series ■Drive system: 4WD

Product introduction

“No compromise in pursuit of ride comfort! Three sacred treasures that continue to evolve!”

A genuine stopper that gets in the way when lowering the Hiace.By lowering the vehicle significantly from the standard ride height, the effective stroke of the suspension is drastically reduced, resulting in an unpleasant shock during large bumps.However, if you try to avoid this by driving with the stopper removed, the front tires will violently rub against the wheel house on bumps and curves, and when rebumping, the reaction will cause the car to lift, creating an unstable and even dangerous situation.In addition, the contact between the axle carrier and the floor that occurs on the rear side overlaps, resulting in a ride that is far from comfortable.A "stroke stopper" is an essential item to avoid such negative effects of low-down.By molding two layers of synthetic resin with different hardness, we achieve a high level of shock absorption and stroke control, which are physically contradictory.It also comes with an "adjust plate" that allows you to adjust the operating point of the front bump stopper, allowing for a wide range of setups.

Precautions for use

●This product is a part exclusively for low-down specification vehicles.It is designed to be lowered by 1.0 inch (-25 mm) or more compared to the standard vehicle height.●For 4WD use only ●This product complies with safety standards, but please note that the inspector's judgment will take precedence when it comes to vehicle inspections.●This product uses synthetic resin with low hardness.Please understand that there is a possibility of deformation or crushing due to long-term use.
