80mm auger log splitter for tractor / set ZW2P-080K2
Model: ZW2P-080K2
The ZW2P-080K2 set is intended for building a screw log splitter driven by a tractor via a PTO shaft. The set is based on a solid and durable hub with built-in 6207 bearings, the auger is mounted with an output shaft of type 35A with a diameter of 35mm, it also has an output for the standard power take-off shaft used in agricultural tractors, i.e. 6 splines, 1 and 3/8 inches. The set is equipped with a wood auger (with a replaceable, dowelled tip) with a diameter of 80mm, which is most often used for building basic log splitters for domestic use. The set containing the aforementioned auger is the most universal solution for splitting standard logs up to 30cm in diameter.. For this auger, you can buy an attachment to increase its diameter to 125mm or 150mm. The auger is equipped with a replaceable tip that is secured with a solid cotter pin, so the tip will not fall out when changing the rotation direction.
The presented set was developed based on many years of experience and is entirely manufactured in our company from high-quality materials, using modern numerical machines and technologies - which guarantees trouble-free operation for many years.
What are the advantages of our product:
The hub construction was made of thick-walled pipe and SOLID, proven bearings, which ensures its maximum RELIABILITY.
We offer the highest quality products along with a written 24-month Warranty!
You are buying directly from a POLISH MANUFACTURER!
The specialized design of the Auger allows for smooth and fast screwing into wood.
The drill bit tip undergoes professional heat treatment, which maximally extends its durability and lifespan!
All parts are manufactured in our company, by POLISH employees under strict quality control - by buying our set, you support the Polish economy.
Very good value for money.
Thousands of satisfied customers ALL OVER THE WORLD!
TECHNICAL DATA
Auger with interchangeable tip (pegged):
[S080K2-35A]
Material type: Experimentally selected HIGH-STRENGTH CHROME STEELPROPERLY HARDENED TIP - which guarantees its high durability and lifespanDrill diameter: fi 80mmDrill length: 230mmWorking part length: 175mm Bore diameter for shaft: 35mmDrill Mount with Shaft: two M12 screws, which guarantees correct operation in both directionsDeep left-hand thread of the drill bit with a saw-like shape ensuring free screwing into woodThe tip is locked with a 12mm diameter expansion plug! thanks to which the appropriate strength of the connection is maintainedReplaceable tips available in continuous sale!Recommended drill speed: 400-600 rpm
PARTS OF THE AUGER:
Drill body (1):
[K-S080K2]
Body length: 140mmLength of the working part of the body: 85mmInterchangeable tip mount: 12mm expansion plug!!
Replaceable tip:
[SWK2]
Material type: Experimentally selected HIGH-STRENGTH CHROMIUM STEELPROPERLY HARDENED TIP - which guarantees its high durability and lifespanTip length: 115mmLength of the working part of the tip: 90mmMounting in the body: 12mm expansion plug!!Tips available for continuous sale
Base set:
[ZW2P]
Hole spacing: 95mm x 75mm
Hub:
[PA6207]
Housing length: 150mm with two built-in solid bearings 6207ZZHousing diameter: fi 82mmHub base: 120mm x 100mmHub base - hole spacing: 95mm x 75mmHub base - diameter of holes: fi 10.5mm
Roller:
[WW2P]
Material type: Experimentally selected HIGH-STRENGTH CHROMIUM STEELShaft length: 300mmDiameter for bearings: fi 35mmDiameter for auger: fi 35mmMounting screw holes for the auger: 2x dia 12mm PTO output: 6 teeth, 1 and 3/8 inches
