90mm universal auger splitter / set ZWK2U-090K2
Model: ZWK2U-090K2
The ZWK2U-090K2 set with a pulley is intended for building a screw log splitter driven by an electric motor, internal combustion engine, or from a tractor via a PTO shaft.. The set is based on two self-aligning pillow block bearings type UCP207, the auger is mounted with a 35A output shaft of 35mm diameter, the pulley is mounted on a 35mm diameter shaft, keyed with a 10mm key and secured with two circlips. It has an output for a standard power take-off shaft used in agricultural tractors, i.e., 6 splines, 1 and 3/8 inches. The set is equipped with a wood auger (with a replaceable, dowelled tip) with a diameter of 90mm, which is most often used for building solid log splitters for domestic use. The set containing the aforementioned auger is the most universal solution for splitting standard logs up to 40cm in diameter.. The auger is equipped with a replaceable tip that is secured with a solid cotter pin, so the tip will not fall out when changing the rotation direction.
The presented set was developed based on many years of experience and is entirely manufactured in our company from high-quality materials, using modern numerical machines and technologies - which guarantees trouble-free operation for many years.
What are the advantages of our product:
The construction was based on self-aligning bearings, allowing them to adapt to an uneven base.
We offer the highest quality products along with a written 24-month Warranty!
You are buying directly from a POLISH MANUFACTURER!
The specialized design of the Auger allows for smooth and fast screwing into wood.
The drill bit tip undergoes professional heat treatment, which maximally extends its durability and lifespan!
All parts are manufactured in our company, by POLISH employees under strict quality control - by buying our set, you support the Polish economy.
Very good value for money.
Thousands of satisfied customers ALL OVER THE WORLD!
TECHNICAL DATA
Auger with interchangeable tip (pegged):
[S090K2-35A]
Material type: Experimentally selected HIGH-STRENGTH CHROME STEELPROPERLY HARDENED TIP - which guarantees its high durability and lifespanDrill diameter: fi 90mmDrill length: 255mmWorking part length: 195mmDiameter of the hole for the shaft: 35mmDrill Mount with Shaft: two M12 screws, which guarantees correct operation in both directionsDeep left-hand thread of the drill bit with a saw-like shape ensuring free screwing into woodThe tip is locked with a 12mm diameter expansion plug! thanks to which the appropriate strength of the connection is maintainedReplaceable tips available in continuous sale!Recommended drill speed: 400-600 rpm
PARTS OF THE AUGER:
Drill body (1):
[K-S090K2]
Body length: 165mmLength of the working part of the body: 105mmReplaceable tip mount: 12mm expansion plug!!
Replaceable tip:
[SWK2]
Material type: Experimentally selected HIGH-STRENGTH CHROMIUM STEELPROPERLY HARDENED TIP - which guarantees its high durability and lifespanTip length: 115mmLength of the working part of the tip: 90mmMounting in the body: 12mm expansion plug!!Tips available for continuous sale
Base set:
[ZWK2U]
Hole spacing: 141mm x 127mm
Self-aligning bearing:
[UCP207]
Shaft bore diameter: 35mmBearing height: 93mmBase - width: 48mmBase - length: 167mmBase - height: 47.6mmBase - hole spacing: 127mm (3mm adjustment)Base - diameter of holes: fi 17mm
Roller:
[WWK2U]
Material type: Experimentally selected HIGH-STRENGTH CHROMIUM STEELShaft length: 410mmDiameter for bearings: fi 35mmDiameter for auger: fi 35mmMounting screw holes for the auger: 2x dia 12mm Diameter for the pulley: 35mm PTO Output: 6 teeth, 1 and 3/8 inches
Pulley:
[K2X17-200-35-K10]
SOLID STEEL PULLEY - we do not sell brittle cast iron pulleys!Diameter: fi 200mmShaft hole diameter: fi 35mmKeyway hole (groove): 10mmNa V-belts: 2X17mm
