4 Channel Optocoupler Relay Module Board High & Low Trigger 5V 12V 24V(5V)

Features: Adopt patch photocoupler isolation, strong driving ability, stable performance. Trigger current is 5mA. Module operating voltage is 5V,12V,24V for choice. Each path of the module can be triggered by the high level or low level through a jumper setting. Fault tolerant design,even if the control line breaks,the relay will not move. Power indicator light (green), 4 way relay state indicator light (red). Humanized interface design, all interfaces can be directly connected through the terminal , very convenient. Four fixing bolt holes are provided. Specification: Weight: 60g 2.1oz Common interface load: AC 250V 10A, DC 30V 10A Module Size (L*W*H): 73*50*18.5mm 2.9*2*0.7inch Bolt Hole: 3.1 mm; 67*44.5mm (spacing) Voltage: 5V, 12V, 24V (Optional) Module interface: 1. DC + : connected to the positive pole of power supply (voltage is required for relay, 5V, 12V and 24V for choice) 2. DC : connect to the power negative pole. 3. IN1 IN4: according to the setting of each circuit, the corresponding relay can be controlled with high or low level to suck in. Relay output terminal: with 12 lines of interfaces, all interfaces can be directly connected to , convenient for users to use 1. NO1 NO4: the relay normally opens the interface, and the relay is suspended before it is sucked in, and is connected with COM after it is sucked in. 2. Common interface of relay COM1 COM4. 3. NC1 NC4: relay normally closed interface. The relay is short connected with COM before it is sucked in and suspended after it is sucked in. High and low level trigger selection terminal: 1. S1 S4 is the high low level trigger selection of relay 1 4 channels successively; 2. Com and low short connection, the corresponding relay for low level trigger, com and high short connection for high level trigger. Package List: 1 x Relay Module.
