Features:
*Versatile Voltage Adjustment: This step-up boost converter allows for an input of 12V while providing an adjustable output range of 12-50V, making it adaptable to various electronic devices and applications.
*Constant Current Supply: Designed to deliver a consistent current output, this power supply is great for driving high-power LED lights, make sure stable performance for your lighting needs.
*Portable Power Solution: With the capability to serve as a car power supply, it can efficiently power laptops, for PDAs, and other digital products, providing convenience.
*Good Friendly: Perfect for hobbyists, this device enables you to create your own mobile notebook power supply by pairing it with a high-capacity / pack, allowing for lightweight and portable .
*Solar Panel Regulation: The converter functions effectively as a solar panel regulator, enabling the charging of rechargeable / batteries, making it an excellent choice for sustainable energy projects.
Specifications:
Part Name: 400W boost constant current
Material: Metal,Plastic
Size: Approx. 67mm*48mm*28mm
properties: non-isolated step-up (BOOST)
Input voltage: DC8.5V-50V
Input current: 15A (MAX) exceeds 8A please enhance heat dissipation
Quiescent current: 10mA (12V liter 20V, the output voltage, the higher the current will increase too quiet)
Output voltage: 10-60V continuously adjustable
Constant] range: 0.2-12A
Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation)
Operating for frequency: 150KHz
Conversion efficiency: up to 96%
Overcurrent protection: yes
Input reverse polarity protection: no
Installation: 4 2.55mm screw holes
Connection: Connection Output
Color: As shown in the picture
Package Content:
1 x boost constant current
Note:
1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
