6V-30V Input PWM Motor Controller 0.56in LED Display Motor Speed Regulator For DC Motors

Label:Yes [Technical Parameters] Working voltage is DC 6 V to 30 V, working current is 6 A, and upper current is 8 A. [Positioning Speed] The knob enables 0% to 100% adjustment, and the 0 to 100 value is shown on the digital display, making it convenient to set the speed and improve equipment efficiency.

[LED Display] 0.56 in (14.2 mm) 3 digit oversized LED digital display with a display range of 000 to 100, allowing you to see clearly in harsh conditions.

[Potentiometer Specifications] The governor delivers strong performance. Potentiometer resistance is B100K, wire length is 20 cm (7.87 in), and opening is 8 mm (0.31 in). [General Specifications] The frequency of this DC motor governor is 16 kHz. The motor runs quietly at low speed and provides strong torsion at low speed.

Item Type: DC Motor Speed Controller Material: ABS Color: Multicolor Applicable Voltage: DC6V-30V Applicable Current: Rated Current 6A Maximum Current: 8A Speed Range: 0%-100% Product Frequency: 16khz (The motor is quiet at low speed and full of torsion at low speed) Potentiometer: Resistance Value B100K, Wire Length: Approx. 20cm / 7.87in, Opening Hole: Approx. 8mm / 0.31in Size: Approx. 79 x 42 x 24mm(3.11 x 1.65 x 0.94in)

Package List: 1 x Motor Speed Controller

Note: Make sure the power is turned off before attempting to wire the controller.
